Flexi – Countertop Lift System

Kitchen countertop lift system, available with electric or manual height adjustment (30 cm). The manual model is operated with a handle while the electric model is operated via a control switch.

Item no.:

Flexi – Countertop Lift System

Kitchen countertop lift system, available with electric or manual height adjustment (30 cm). The manual model is operated with a handle while the electric model is operated via a control switch.

Item no.:

Power

Electric / Manual

Height adjustment

30 cm (65-95 cm)

Operation

Control switch / Detachable handle

Max. user weight

150 kg evenly distributed

Description

Flexi is a series of wall-mounted worktop lift systems available with manual or electric height adjustment (30 cm). The worktop lift system allows you to easily adjust the worktop for the perfect working height for both persons sitting or standing. Corner solutions are also available with the Flexi systems so that the sink, hob and preparation area can be adjusted instantly together.

Movement of the adjustable worktop lift system is by push button (electric) or by using a handle (manual). Smartbox for connecting the safety systems of several units – In principle, the collision protection devices of one or more VertiInside, Diagonal and Flexi(Electric) can be connected. Each system requires its own Smartbox.

Accessories

Item no:

Support Arms

Support arms should be chosen if the worktop depth differs from 58-62 cm.

Item no:

Special Support Arms

Special support arms should be chosen if more space is needed for cutouts in the worktop.

Item no: 30-66010

Reprogramming Of Travel

If limited travel is desired, this can be ordered; only the top position can be changed.

Item no:

Supporting Foot

Feet can be selected if the wall is not strong enough to support the Flexi frame. Available in two lengths.

Item no: 30-67672

Spacer Bracket

Spacer brackets move the Flexi frame 7 cm out from the wall.

Item no:

Cover Caps For Flexi Legs

Cover cap with telescopic for Flexi legs, available in 2 variants depending on whether feet are mounted on the Flexi leg.

Item no:

Safety Strips

Safety strip (2.2kOhm) for mounting under the front edge available in various lengths; we always recommend having a safety strip on 3 sides of the tabletop. Connection cable included at 150 cm.

Item no: 30-67760

Brackets For Concealment Panels

Flexible brackets for mounting cover plates that cover the entire area under the Flexi frame. Cover plates are not supplied by Ropox.

Item no: 30-67635

Plumbing Cover

Telescopic cover for water installations, white.

Item no: 30-67841

Large Control

Control, large press pad 14 x 7 cm, white.

Item no: 30-90591

Wireless Remote Control

Height adjustment via wireless remote control with Bluetooth connectivity through a phone.

Item no: 30-69002

Increased Safety

Smartbox can interconnect multiple safety circuits from FlexiElectric, 4Single Electric, Verti-Inside, and Diagonal to enhance internal pinch safety.

Item no:

Extension Cables For Safety Stop

Extension cables if safety stop wires need to be routed through a wall or tall cabinet.

Item no: 30-40660

Extension Cables For Control

Extension cables if the control is placed far away.

Item no: 30-67840

Control Panel

Standard control unit for electric height adjustment.

Item no:

Kitchen Sinks

Stainless steel sinks 40x34 cm including insulation plate under the sink. Available in 2 depths: 13.5 cm and 10 cm.

Item no: 30-45010

Flexible Plumbing Kit

Plumbing kit includes flexible connection hoses and drain.

Item no: 96000629

Split Cable

Split cable allows an additional control button to be connected.
Specifications

Height adjustment

30 cm (65-95 cm)

Max. user weight

150 kg evenly distributed

Operation

Electric model: Control switch

Manual model: Handle

Mounting

Wall-mounted

Dimensions

Frame height: 65 cm
Support arms height: 5 cm
Worktop length: 60-300 cm
For worktop depth: Standard: 58-62 cm. Also available for 38-72 cm.

Please indicate length of worktop when ordering.

Legs and support arms

Number of legs and support arms depends on the size of worktop.

Power source (Electric model)

Hard-wired

Power supply (Electric model)

220-230V~ / 50-60Hz, 5.0A

Lifting speed (Electric model)

32mm / sec, approx.

Materials

Welded steel tubes St. 37 Aluminium alloy 606045-T6 Stainless steel spindle and various plastic components

Surface treatment

Powder coated

Included

Various adjustment brackets, spacers for walls, cable bearer etc. are included.

CE certified
