Vision High-Low – Electric Height Adjustable Desk

Height adjustable desk with extra long adjustment range of 65 cm and 0-71 ° tiltable tabletop. The desk height is adjusted via a control switch. Available in two lengths.

Item no.:

Vision High-Low - Electric Height Adjustable Desk

Vision High-Low - Electric Height Adjustable Desk - Image 2

Vision High-Low – Electric Height Adjustable Desk

Height adjustable desk with extra long adjustment range of 65 cm and 0-71 ° tiltable tabletop. The desk height is adjusted via a control switch. Available in two lengths.

Item no.:

Table size

120x60 cm90x60 cm

Tiltable tabletop

Power

Electric

Extra long adjustment range

65 cm (62-127 cm)

Tiltable tabletop

0-71 °

Operation

Control switch

Sizes

90x60 and 120x60

Integrated steel plate

Description

Vision High/Low is an electric height adjustable table with extra long adjustment range (65 cm) and tiltable tabletop. The height is easy to adjust to working position by a light pressure on the control switch. The tabletop is tiltable ( 0-71°) and shortens the visual distance to the documents on the tabletop, which is convenient particularly for weak-sighted and users with reduced arm function.

The tabletop has a matte surface, therefore no annoying glare. The MagRule magnet keeps documents in place even when the tabletop is tilted. The table can be supplied with a battery solution making the table completely cordless.

Accessories

Item no:

Arm Support

Extra under arm support - can easily be attached to the table and adjusted, including bag and hook. Max user load 25 kg per arm.

Item no: 20-60821

Factory-installed Wheels - Vision High/Low

Factory-installed brake wheels (set) that make it easy to move the table around. Does not increase the table height. Ordered with the table.

Item no: 20-60823

Wheels For Reordering - Vision High/Low

Brake wheels (set) for retrofitting that make it easy to move the table around. Does not increase the table height.

Item no: 50200-000

Magnet

1 pc. magnet that can be placed freely over the entire tabletop to hold paper. Can only be used on tabletops with an inclined position. White colour.

Item no:

MagRule

Magnetic strip that can be placed freely over the entire tabletop to hold paper or a book. Available in 2 different lengths. Can only be used on tabletops with an inclined position.

Specifications

Power

Electric

Height adjustment

65 cm (62-127 cm)

Tiltable tabletop

Type A: Without tilt. Type B: 0-71 ° tiltable tabletop

Feature

Integrated steel plate

Max. load on the table (static)

100 kg evenly distributed

Max. load during lifting (dynamic)

80 kg

Max. load on tilted tabletop (static)

30 kg

Max. load during tilting the tabletop (dynamic)

4 kg

Power source

Hard-wired
Battery can be purchased (Accessory)

Power supply

230VAC / 2.5A / 50 Hz – Alternatively 100VAC / 50/60 Hz

Duty circle

Max. 10 % conform to 2 min. active / 18 min. Pause

Speed

Approx. 38 mm/sec

Materials

Frame: Steel St. 37. Various plastic components.
Tabletop: Etronit-M laminate

Surface treatment

Powder coating, various colours
Chromating

Standard colour

Light grey

Dark grey

CE certified

Mounting Instructions

Downloads

Datasheet (pdf)

Brochure (pdf)

Ropox Individual Table solutions

Manual (pdf)

Ropox User manual - Vision High-Low
