SwingLine – Washbasin with 180 ̊ Rotation

SwingLine is a manual adjustable washbasin that rotate and swing, giving wheelchair users maximum turning space. SwingLine is adjusted manually with a handle.

Item no.:

SwingLine – Washbasin with 180 ̊ Rotation

SwingLine is a manual adjustable washbasin that rotate and swing, giving wheelchair users maximum turning space. SwingLine is adjusted manually with a handle.

Item no.:

Feature

The arm swings 180 ̊

Operation

Handle

Manual height adjustment

15 cm

Configuration

Visible / Hidden installations

Description

SwingLine is a manual height adjustable bathroom sink (15 cm without Dock-In, 20 cm with Dock-In) that is recommended for both seated wheelchair users and standing users. You can rotate the sink by 180˚, which allows the sink to be pulled to the toilet. With SwingLine, users can safely wash their hands while seated on the toilet.

You can move the basin when required, e.g. push the sink to the corner when you need extra room for turning the wheelchair. The simple design without any dirt traps makes it easy to clean.

Specifications

Power

Manual

Operation

Handle

Max. User weight according to ISO 17966:2016

Incl. dock-in:

245 kg when the washbasin is locked in the Dock-in.
80 kg when the washbasin is out of the Dock-in.

Excl. dock-in: 80 kg.

Materials

Gelcoated composit. Aluminium. Stainless steel. Surface treated steel

Standard colour

White. Plastic parts are grey

Included

Mixer tap, flexible connecting hoses and flexible waste as well as a handle. The washbasin has no overflow and no intergral trap – this can be purchased.

Standard

Manufactured in accordance with the following standard: DS/ISO 17966:2016

CE certified

Mounting Instructions
