Item number
30-67840
Installation
The control switch for electric height adjustment must be fitted in the wooden front fascia of the kitchen worktop. Choose the required position in the front fascia and drill an 18 mm in dia. hole. Push the cable through the hole in the fascia from the front.
The control switch has double-adhesive tape on the back. Remove the protective paper and fit the
control switch on the wooden front fascia.
Fit the DIN plug of the cable on the control switch. After fitting the socket, fasten the cable under the
worktop with the cable bearer so that it does not sag.
Included
150 cm cable provided with a DIN plug
Dimensions
3 x 6 cm incl. 150 cm cable
