4Single Frame – Height Adjustable Table Frame

Height adjustable table frame available in various sizes with manual or electric height adjustment (30 cm).

Item no.:

4Single Frame – Height Adjustable Table Frame

Height adjustable table frame available in various sizes with manual or electric height adjustment (30 cm).

Item no.:

Table frame

30 cm electric / manual adjustment

Control switch / Handle

Max. weight: 150 kg

Size: 60-200 x 60-200 cm / 201-300 x 60-200

Description

4Single is a height adjustable table frame available in three height adjustment ranges (30 cm) and with manual or electrical height adjustment. Perfect for kitchens, for rooms with large space, family rooms, and dinning-rooms and for many various kitchen activities. You can adjust the frames by using a handle or controller. If you mount robust brake wheels on the frame you will get a very mobile table that can be placed almost anywhere in the room according to individual needs.

The table frame can be designed according to individual requested sizes and for almost every kind of tabletops. You can decide the width, length and tabletop materials and make the table just as you like it.

Accessories

Item no: 50-41600

Wheels For 4Single

Four pieces of brake wheels that makes the 4Single table frame fully mobile, and increases the height of the frame by +6.5 cm.

Item no: 50-41605

Floor Mounting

If the table frame needs to be secured to the floor, these four mounting brackets can be easily installed on the 4Single table, providing stable fixation when required.

Item no:

Kitchen Sinks

Stainless steel sinks 40x34 cm including insulation plate under the sink. Available in 2 depths: 13.5 cm and 10 cm. Choose variant

Item no: 30-45010

Flexible Plumbing Kit

Flexible plumbing kit for kitchen sink. Includes connection hoses and a flexible drain hose. This item is compatible with Flexi countertop frames, FlexiPlus, and 4Single frame.

Item no: 30-66010

Reprogramming Of Travel

If there are obstacles preventing the frame from moving through its full range, this item can be ordered for a limited range of movement. Only the top position can be adjusted.

Item no:

Extension Cables For Safety Stop

Extension cables that makes it possible to route the safety stop wiring through walls, tall cabinets, or other installations—ensuring full functionality even when components are positioned farther apart. Choose variant

Item no: 30-40660

Extension Cables For Control

Extension cables if the control is placed far away. L = Straight 350 cm + 45 cm spiral.

Item no:

Safety Strips

Discreet safety strip (2.2kOhm) for electric variants of the Flexi worktops, stopping movement instantly if contact or obstruction is detected under the worktop. Available in various lengths.

Choose variant

Item no: 30-69002

Increased Safety

Combine all kitchen products in a safety network with the Smartbox. The system will register any activation of a safety stop in the network and stop all movements until the jamming situation has been eliminated. Compatible with FlexiElectric, Diagonal, VertiInside and 4Single Electric.

Item no:

Battery Operation for 4Single

Battery solution that allows the 4Single table to be moved and operated without a power connection. Choose between the standard battery or the high-capacity battery for increased lifting capacity. A version compatible with safety strips is also available. Choose variant

Item no:

Increased Lifiting Capacity

Optional upgrade for the Ropox 4Single table frame, increasing the lifting capacity to 250 kg for enhanced strength and durability. Choose variant

Specifications

Height adjustment

30 cm

Operation

Electric model: Control switch

Manual model: Handle

Tabletop dimensions

Height: 55-85 cm / 65-95 cm / 78 – 108 cm

Length: 60-200 cm / 201-300 cm

Width: 60-200 cm

Frame

The frame is 4 mm smaller than the worktop as standard. Frames are ordered according to the size of the worktop. If the overhang shall be larger – please contact Ropox.

Max. load of frame

150 kg evenly distributed

Increased load of frame (Electric model)

250 kg – height adjustment 55-85 cm (Item no. 50-41320)
250 kg – height adjustment 65-95 cm (Item no. 50-41420)

Lifting speed for increased load of frame: Approx. 12 mm/sec. – approx. 25sec.

This is an accessory that can be purchased.

Power source (Electric model)

Hard-wired.
Battery solution can be purchased (Accessory)

Power supply

220-230V~ / 50-60Hz, 5,0A

Lifting speed

Approx. 32 mm/sec. – approx. 10 sec.

Safety (Electric model)

Safety strip can be purchased (Accessory)

Materials

Welded steel tubes St. 37 and various plastic components

Surface treatment

Blue chromate, powder coating: Standard CWS 81283 RAL 7021 mat

Standard color

Dark grey structure – RAL 7021

CE certified

Line drawing
