VertiElectric – One frame system
- Installation & maintenance
Electric height adjustable system for wall cupboards.
Height adjustment 30 cm.
For cupboards heights 70-90 cm.
For cupboards width 40-120 cm – use one frame.
It is possible to mount several cupboards on one system.
Installation & maintenance
Manufactured in accordance with the following standard: DS / EN12182-2012
Max. load: 80/120 kg evenly distributed
Box Height: 70-90 cm
Box Width: 40-180 cm
Depth of frame: 50 cm
VertiElectric is a lift system for upper wall cabinets in the kitchen. The system makes it possible to lower and raise the cupboards from 30 cm up and down to provide seated users easy access to the cabinet content.
Whether you are furnishing a new kitchen or if you are retrofitting an existing, you can use VertiElectric to make it handicap friendly. The system fits every standard size wall cupboard. This means that you can make ordinary kitchen cupboards accessible to people with mobility disabilities.
The lift system is only 5 cm deep and is mounted behind the cupboard itself. The height adjustment is set with a small control switch on the front fascia of the kitchen worktop or with a remote control.
Using VertiElectric elderly and disabled people become more self-reliant in the kitchen.
Control switch & press pad - spiral extension cableItem no.: 30-40660
Safetystop plate - single plateItem no.: 30-41604 to 3041612
Safetystop plate - Two-piece plateItem no.: 30-41613 to 30-41618
Light for safetystop plate – 1 LED spotItem no.: 30-42604 to 30-42606
Light for safetystop plate – 2 LED spotItem no.: 30-42607 to 30-42612
Light for safetystop plate – 3 LED spotItem no.: 30-42613
Light for safetystop plate – 4 LED spotItem no.: 30-42614 to 30-42618
Large press padItem no.: 30-67841
Safety strip & stop - extension cableItem no.: 30-67870
For safety strip & stop - spiral extension cableItem no.: 30-67871
SmartboxItem no.: 30-69002
