All-in-One – Walking Trainer

The walking trainer system is a mobile personal lifter for people with limited mobility who need help with walking training.

Item no.:

All-in-One – Walking Trainer

The walking trainer system is a mobile personal lifter for people with limited mobility who need help with walking training.

Item no.:

Power

Electric

Max. user weight

150 kg / 200 kg

Height adjustment

150-190 cm

Description

The Walking Trainer is a therapy device that promotes a normal walking pattern by controlling weight bearing, balance and posture during walking therapy. The medical staff, using different slings, can lift people up to 150/200 kg, depending on the chosen variant of lift. The frame from our normal All-in-One provides the basic structure – this means the Walking Trainer can be converted into a patient or stand up hoist. A “forked shaped” lifting bar and “handlebar unit” are mounted to the basic frame to give safe support while allowing the patient to look over the unit when walking. Our special Walking Trainer sling is required to perform the lifting and training.

Specifications

Power

Electric

Mounting

It is mounted with two guide devices to ensure it moves forward in a straight line.

Configuration

Possible to convert to another model
The legs are electrical operated.

Height adjustment

150-190 cm

Safe working load

Approx. Number of lifts per charge

150kg = Approx. 100
200kg = Approx. 75

Lifting speed

≈ 15mm/s

Power supply

100-240V ~50/60Hz

Intermittence

2 min use / 18 min pause

IP rating

IPX4

Material

Spreader bar: St37 tube construction with powder coating

Line drawing
Downloads

Datasheet (pdf)
